Cleaning system
Series 28
The series is optionally available with a 100 l auxiliary tank including filtration, recirculation, and tank heating.
Technical Data Type 23-03 T
Overall machine dimensions
(incl. tank and drip tray)
Width | 1692 mm |
Depth | 1150 mm |
Height | 2010 mm |
Properties | |
Cleaning levels | 2 |
With raised chamber | up to 4 |
Chamber volume | 685 l |
Additional tank | 100 l |
Washing temperature max. | 93 °C |
Maximum drying temperature | 110 °C |
Rated pump power | 1800 l/min. |
Suitable for cleaning:
- Electronic assemblies, PCBs, and misprints
- Glass and plastic lenses
- Glass and plastic bottles
- Plastic containers
- Metal containers
- Metal base plates
- Stencils
